Specifications
| Type | Respirable Dust Sampler |
| Weight | 50 kg |
| Voltage | 220V |
| Condition | New |
| Power Source | AC |
| Features | Durable, Eco Friwndly, Fine Finished, Precise Design |
| Warranty | ALL VAIBHAV PRODUCTS CARRY 14 MONTH WARRANTY |
| Display | Digital |
| Flow Rate | Free flow 0.9 – 1.4 m3/min free flow with filter and more than 2.0 m3/min without filter, |
| Automation Grade | Fully Automatic |
| Brand Name | VAIBHAV |
| Power | AC |
| Basic features | Brush less belt driven almost maintenance free & almost zero consumable blower, electronic digital manometer in place of glass manometer, digital flow indicator & volume totalizer (Digital Manometer), |
| Particulate Sampling | 10micron down to 0.1micron(depending upon filter used) A cyclone is used for fractionating the dust into 2 fractions, D50 cutoff for cyclone is at 10microns. RSPM is accumulated on the filterpaper |
| Filter Holder | To accommodate any standard filter paper of 25 x 20 cm, particulate bigger than 10 micron collected in separate dust cap under the cyclone |
| Filter Media | 8” X 10” (203mm X 254mm / 20.3cm X 25.4 cm) Glass microfiber filter for common use and EPM 2000 or equivalent for special monitoring / research work |
| IS Reference | Match the requirement prescribed in BIS 5182(Part-23) 2006 |
| Timer Recorder | 0 to 99999.99 hrs. time totalizer records the running time in hours |
| Clock / Timer | Programmable Real Time control system with control of automatic start & stop, number of required intervals can be programmed, Timer is used to start and shut off the sampler at preset time |
| Sampling Time | 30 hours (maximum) for single sampling |
| Power Requirement | Single phase AC 220 volts, 50 Hz, sampler unaffected by +/- 10 % fluctuation in supply voltage. For proper operation and safety a good earth connection is mandatory |
| Dimension | Approximately 410mm X 300mm X 700mm |
| Particle Size | Separate provision for collection of Respirable and non Respirable (less than and greater than 10 micron) size particles |
| Construction | The body of RDS is robust enough to withstand impacts and vibration in transportation; it is made of heavy aluminum sheet. |
| Night View | Provision has been made for light in the sampler for taking reading during dark area and in night hours |
| Hardware | Only SS corrosion free hardware used in sampler |
| Digital Display | 16 character, 2 line LED display with 5 key operation |
Additional Information
| Product Code | VRDS 500EBL |
| Min. Order Quantity | 1 Set(s) |
| Port | AHMEDABAD |
| Payment Terms | L/C, D/P |
| Delivery Time | READY STOCK |
SPECIAL FEATURES
Digital Manometer with volume totalizing (Waterless manometer, no need of filling and adjusting zero lever with distilled water)
Provide Sample volume in m3 at any stage of sampling on display
Modular design for easy operation
Sturdy aluminum construction with SS hardware
Glass manometer tube brakeage during transportation & water evaporation is eliminated due to digital manometer
Low Noise during operations
Less variation in flow even chocking of filter
Totally eliminated of EMI
Compact, Portable, Easy to Operate-Transport & Handle
Arrangement for Parallel Gaseous sampling
Light provision for working in night & dark area
Design to runs continuously 24 hours or more
Castor provide easy internal movement
Common Body (Housing) structure for all the model which will easy converted to any of the VRDS 500series
Suitable for Outdoor Use, Corrosion free lockable housing
