FINE DUST SAMPLER VFDS 113MFC

Quick Contact

VAIBHAV EQUIPMENT SERVICE

Mr. PRITESHKUMAR VINODKUMAR SHAH

5, Chintamani Society, Ramnagar, Sabarmati, Sabarmati, Ahmedabad, Gujarat - 380005, India

+91-9427380743


Price : INR 100.00


SPECIAL FEATURE :

 Microprocessor based controller

 maintain constant air sampling rate of 16.7 LPM(1m3/Hr.) even during in high filter chocking or in high dusting area

 Programmable timer to auto start and stop sampling

 Data can be exported to PC in Excel format using pen drive

 Auto Leak check

 Compact , Portable, Easy to Operate & Handle

 Arrangement for Parallel Gaseous Sampling

 Large alpha numerical LCD display

 Dual data recording, internal and in easy removable memory stick

 Filter Holder is design to accept any standard 47 mm diameter filter.

 Microcontroller based data logger display and record Air & Filter temperature, Filter & Barometric Pressure, Flow rate, Air volume sampled, Elapsed time

 Auto shut off facility if flow rate falls below 1m3/hr, due to excess filter chocking, Temperature variation, Pressure etc..

 Filter holders fitting in the sampler are done such so that these are remain suspended in air & thus not affected by heat of motor fitted in lower cabinet of the sampler, filter temperature records are available

 Suitable for Outdoor Use, Corrosion free lockable housing for wins impactor and filter holder

 Design to runs continue 24 hours or more at constant flow rate of 1m3/hr

 Display values of all parameters are upgraded every 30 seconds

 User friendly design having low operating cost, Pump assembly is brushless and noiseless

 PM 2.5 impactor is developed as per USEPA published standard design,

 Meets the requirement of Pollution Control Board for Fine Dust Sampling

 Sample can be used for Accurate Particulate Sample Collection of PM2.5 / PM10 dust monitoring gravimetrically


Specifications

Type FINE PARTICULATE SAMPLER (PM 2.5 SAMPLER)
Power Source Electric
Warranty 14 MONTHS
Automation Grade Automatic

Additional Information

Product Code VFDS 113MFC
Min. Order Quantity 1 Set(s)
Port EX WORK AHMEDABAD
Payment Terms L/C, T/T
Delivery Time READY STOCK (EX-STOCK)
