Dichotomous Sampler - VDS 131

Quick Contact

VAIBHAV EQUIPMENT SERVICE

Mr. PRITESHKUMAR VINODKUMAR SHAH

5, Chintamani Society, Ramnagar, Sabarmati, Sabarmati, Ahmedabad, Gujarat - 380005, India

+91-9427380743


Price : INR 100.00


SPECIAL FEATURES

  • PM10 & PM25 impactor as per design standardize by USEPA
  • Virtual impactor based collection of coarse and fine fraction on separate filter enable simultaneous monitoring of PM10 & PM2.5
  • Auto shut off of sampler if pressure drop exceeds safe limit so that filter integrity is maintained
  • Constant sampling rate of 1m3/hr maintained by Microprocessor base Mass Flow base electronic controller that is unaffected by change in pressure drop due to dust deposit on the filter
  • The flow rate of PM2.5 and PM2.5 are controlled individually by flow controller
  • The PTFE filter with low absorptivity for gas and moisture is used
  • Data transfer to USB memory stick for general – purpose is available for ease in recovery of data from remote field
  • locations, the recorded file is compatible with MS Excel and easily opened in a PC without need of additional software.
  • Data logger continuously display and record Air temperature, Filter Temperature, Barometric pressure,
  • flow rate and air sampler volume, elapsed time,
  • Inbuilt programmable timer to control start and stop times of sampler
  • All system parameters recorded at 5 min interval in internal 4GB non volatile memory.
  • Brushless, Oil free, pump practically requires no maintenance.
  • Arrangement for Parallel Gaseous sampling




Specifications

Type DICHOTOMOUS SAMPLER
Weight 20-30kg
Voltage 220V
Condition New
Power Source Electricity
Features Durable, Eco Friwndly, Fast Cleaning, Fine Finished, Precise Design
Warranty 14 MONTHS
Display Digital
Flow Rate 0.5-1m3
Automation Grade Fully Automatic
Brand Name VAIBHAV
Power 220 VC AC 50 Hz
SAMPLING OBJECT FINE PARTICULATE(PM 2.5) AND RESPIRABLE PARTICULATE (PM10)
PM 2.5 & PM 10 SIZE SEPARATOR PM10 Impactor confirm to USEPA design and its reference method, sample collected in separate 37mm dia pure nylon membrane filter having 1mm thickness
PM 2.5 & PM 10 SIZE SEPARATOR.. developed specially for acidic dry deposition & 37mm dia, 2mm thickness PTFE membrane filter with PMP (Poly methyl pentene) supporting ring
FLOW RATE Fine-particle flow : 0.9 m3/hour or 15.0 L/min; Coarseparticle flow: 0.1 m3/hour or 1.67 L/min
FLOW INDICATOR & VOLUME TOTALIZER Acrylic body rotameter along with Digital flow indicator and volume totalizer with time stamp in non volatile memory
DISPLAY & RECORDER like current flow, totalizer sample volume, elapsed time, Temperature, Pressure and on large display with back light
HOUSING / CABINET Frame mount main panel provided with lockable powder coated aluminum cabinet to resist against all weather and worst environment conditions
SAMPLING PROB / CLASIFIER USEPA PM10 inlet (coarse particulate) and PM10-2.5 inlet (fine particulate) virtual impactor assembly Impactor based on USEPA Design.
FILTER HOLDER 37mm coarse and fine particulate filter holder
VACUUM PUMP Mono block, oil free, light weight, maintenance free long life, easy to handle and carry induction motor with more than 70 LPM free flow capacity.
CALIBRATION UNIT Optional NABL certify flow calibrator with all necessary fitting and accessories available at an extra cost.
ACCURACY 5 % accuracy at 1.0m3/hrs will maintain through microprocessor base event controller data logger it will monitor and control flow through pneumatic constant flow controller.
DATA DOWNLOADING Transfer file will be easily open in MS excel. Logger can store upto 4 GB Data in its own memory in non volatile form.
SPECIAL FEATURES Data collection from logger using USB Stick, MS Excel Compatible file without need of additional software
STANDARD ACCESSORIES Adopter for Leak check & flow rate calibration
FLOW RATE COMPENSATION Perform automatically by system using sensors of ambient temperature and barometric pressure sensors
ELAPSED TIME INDICATOR Real time clock based record the operation time for each sample in hours and minute
WARRANTY ALL VAIBHAV PRODUCTS CARRY 14 MONTH WARRANTY

Additional Information

Product Code VDS 131
Min. Order Quantity 1 Set(s)
Port EX WORK AHMEDABAD
Payment Terms L/C, D/P, T/T
Delivery Time 2 - 3 WEEK
